MOOG MD serie børsteløse servomotorer

MOOG servmotorer
  • Designed for highly dynamic servo applications where positioning times of 30 mSec or less are often the norm
  • AC Servo Motor (Synchronous)
  • Low inertia, compact length
  • Type of Motor: Totally enclosed, natural cooling (optional fan ventilation)
  • High voltage (600 Vdc Brushless Servo Motor) available
  • Flameproof servo motors available

Kontakt Hydex vedrørende MOOG MD serie børsteløse servomotorer

Type    Brushless Servo Motor
Continous stall torque Natural cooling: 2.2-609 Nm
Liquid cooling: 46-1034 Nm
Maximum torque Natural cooling: 0.5-240 Nm
Liquid cooling: 64.2-2012 Nm
Nominal torque Natural cooling: 1.5-575 Nm
Liquid cooling: 45-1003 Nm
Nominal speed 1400-5500 r/min
Nominal power Natural cooling: 0.85-34.6 kW
Liquid cooling: 9.35-60.4 kW
Rotor interita Natural cooling: 0.78-1985 kg cm²
Liquid cooling: 10.8-1985 kg cm²
Position transducer options Resolver or encoder
Approvals available
Typical applications Plastics Machinery
Die Casting
Metal Forming and Presses
Food and Beverage Processing
Other General Industrial Automation
For mer informasjon Klikk her --- Datablad --- Katalog

Kontakt Hydex vedrørende MOOG MD serie børsteløse servomotorer
