PCB Piezotronics general purpose quartz force sensors

Model 208C01
Multi-purpose ICP®,
10 lb comp, 10 lb tension
500 mV/lb
Model 208C02
Multi-purpose ICP®,
100 lb comp, 100 lb tension
50 mV/lb
Model 208C03
Multi-purpose ICP®,
500 lb comp, 500 lb tension
10 mV/lb

Model 208C04
Multi-purpose ICP®,
1000 lb comp, 500 lb tension
5 mV/lb
Model 208C05
Multi-purpose ICP®,
5000 lb comp, 500 lb tension
1 mV/lb
Model 218C
Multi-purpose,
5000 lb comp, 500 lb tension
18 pC/lb

Applications
• Dynamic Tension & Compression
• Impact & Repetitive Applications
                             • Drop Testing
• Materials Testing
